Author Topic: open Air Filter in b400, fitting...  (Read 9042 times)

Offline 2Fast4U

  • TURBO TYPER!
  • **
  • Posts: 47
open Air Filter in b400, fitting...
« on: March 19, 2006, 07:37:36 AM »
hello, i would like to install an open air filter to my bike,

pictures:











this is the filter, i need 4 of them:





my question is what size of filter i shold be order?!?...:
D=42mm Long =60mm
D=54mm Long =60mm
D=50mm Long =60mm
D=46mm Long =60mm
D=52mm Long =60mm

i need it to fit my GSF400.


thanks , idan.
Logged

Offline Red01

  • Board Homesteader!
  • ***
  • Posts: 8977
  • Are we having fun yet?
open Air Filter in b400, fitting...
« Reply #1 on: March 19, 2006, 10:36:16 AM »
The top picture is a set of BMC filters. Contact Factory-Pro for those. If you don't have a jet kit, you'll need one for any pod filter setup - and Factory-Pro can hook you up there, too. They used to list the B4 pod kit on their site, but I don't see it there anymore, but they ought to be able to hook you up.

Looks like the silver framed bobbed B4 is sporting K&N individual pods. They're a little smaller than the BMC's

The B12 is wearing 2 K&N pods, each one mates to a pair of carbs.

As for the size, I don't know. If no one comes up with the answer, you can always measure the mouth of the carb yourself.
Logged
Paul
2001 GSF1200S
(04/2001-03/2012)
2010 Concours 14ABS
(07/2010-current)

Offline Herr Tod

  • Board Homesteader!
  • ***
  • Posts: 489
open Air Filter in b400, fitting...
« Reply #2 on: March 19, 2006, 11:01:14 AM »
I wouldn't use the filter on the last picture. That one only filters out trees and bricks :roll:
Logged

Offline 2Fast4U

  • TURBO TYPER!
  • **
  • Posts: 47
open Air Filter in b400, fitting...
« Reply #3 on: March 19, 2006, 11:38:17 AM »
can anybady get the information in need from here:

Logged

Offline 2Fast4U

  • TURBO TYPER!
  • **
  • Posts: 47
open Air Filter in b400, fitting...
« Reply #4 on: March 19, 2006, 11:45:07 AM »
or from here:

Logged

Offline gsxr400 racer

  • I find things for a small fee....
  • Site Supporters
  • Board Homesteader!
  • ***
  • Posts: 3344
    • For all your disc golf needs...maybe i can race again someday.lol
open Air Filter in b400, fitting...
« Reply #5 on: March 19, 2006, 11:48:39 AM »
something about that vance and hines mounted like that. I like it!
Logged
1988 gsxr 400 sp (sprint bike)
*  SELLER OF THE 442CC BIG BORE PISTON KIT FOR THE BANDIT 400,GSXR400, GK73 and 76.* And carb kits(orings)too. Email me from here.
has been a wera expert #610 lol

Offline Red01

  • Board Homesteader!
  • ***
  • Posts: 8977
  • Are we having fun yet?
open Air Filter in b400, fitting...
« Reply #6 on: March 19, 2006, 12:31:41 PM »
Quote from: "2Fast4U"
can anybady get the information in need from here:


Nope. The OD of the bellmouth isn't listed on those charts.
Logged
Paul
2001 GSF1200S
(04/2001-03/2012)
2010 Concours 14ABS
(07/2010-current)

Offline interfuse

  • Site Supporters
  • Board Homesteader!
  • ***
  • Posts: 1336
open Air Filter in b400, fitting...
« Reply #7 on: March 19, 2006, 04:23:58 PM »
Get out a set of calipers and measure it to be sure. I measured my carbs and came up with 52mm across x 57.5mm high.
Logged
Mike

'91 GSF400
It's more fun to ride a slow bike fast than a fast bike slow.

Offline 2Fast4U

  • TURBO TYPER!
  • **
  • Posts: 47
open Air Filter in b400, fitting...
« Reply #8 on: March 20, 2006, 05:00:54 AM »
Quote from: "interfuse"
Get out a set of calipers and measure it to be sure. I measured my carbs and came up with 52mm across x 57.5mm high.


what model of suzuki do you have?!?
Logged

Offline interfuse

  • Site Supporters
  • Board Homesteader!
  • ***
  • Posts: 1336
open Air Filter in b400, fitting...
« Reply #9 on: March 20, 2006, 09:38:18 AM »
Quote from: "2Fast4U"
what model of suzuki do you have?!?


Canadian model bandit 400.
Logged
Mike

'91 GSF400
It's more fun to ride a slow bike fast than a fast bike slow.

Offline 2Fast4U

  • TURBO TYPER!
  • **
  • Posts: 47
open Air Filter in b400, fitting...
« Reply #10 on: March 24, 2006, 04:33:07 AM »
from beauty to personality:
http://forums.banditalley.net/viewtopic.php?t=4826



fuel cable 8mm, duel rabber:




brakes - Valvoline Dot4:


open air filters, Koni D=54mm Long =60mm:
Logged

Offline nos

  • TURBO TYPER!
  • **
  • Posts: 26
Re: open Air Filter in b400, fitting...
« Reply #11 on: December 18, 2008, 07:10:43 PM »
where can i get those?
Logged
bikes i own:
Bandit 400
GSR500 Racing bike
RS125 Racing bike
1198 Racing bike

Offline Chris H

  • Board Homesteader!
  • ***
  • Posts: 559
Re: open Air Filter in b400, fitting...
« Reply #12 on: December 19, 2008, 02:43:49 PM »
The B4 carbs bell mouth is oval not round and as interfuse sayz measures-52mm/57.5mm dia.
You may have problems getting the filters to seal correctly, but 54mm or 55mm filters should fit. You can get them in the UK, Calsport sell them on the ebay.co.uk site, they say world wide post is available and you would need a paypal account, you could contact them but a set of 4 is about £100 and then you would have to add postage and also rejet.
http://stores.ebay.co.uk/Cal-Sport/K&N%20Bolt%20On%20Chrome%20Air%20Filters%20XJ600%20FZR400%20XJ900F
« Last Edit: December 19, 2008, 02:52:41 PM by Chris H »
Logged

Offline nos

  • TURBO TYPER!
  • **
  • Posts: 26
Re: open Air Filter in b400, fitting...
« Reply #13 on: December 23, 2008, 05:53:47 PM »
Logged
bikes i own:
Bandit 400
GSR500 Racing bike
RS125 Racing bike
1198 Racing bike

Offline tundrazach

  • TURBO TYPER!
  • **
  • Posts: 29
Re: open Air Filter in b400, fitting...
« Reply #14 on: December 23, 2008, 07:20:57 PM »
those are shipping out of Taiwan, you might want to find a set that are closer to you if you want them any time soon :beers:
Logged
Rebuilding a 1991 B4. Got a lot to do
